Quon
All Quon
Heavy duty range
Quon GW General specifications
Axle configuration
6x4
Engine(Engine series)
GH11
Weight
GVW 20 - 25Ton
Transmission
ESCOT-VI; 7-speed MT; 12-speed MT
Power (Engine power range)
360 - 420Hp
Torque Nm (Engine torque range)
1750; 1900
Brake System
Air Type disk brake of front and rear; Auxiliary brake; UD Extra Engine Brake (EEB); Variable geometry turbo brake
ECS (Emission control system)
Post New Long Term emission regulation
Usage
Mixer; Cargo; Tipper; Spray
Quon GK General specifications
Axle configuration
4x2
Engine
GH11
Weight
GCW 40 - 45Ton
Transmission
ESCOT-VI; 7-speed MT; 12-speed MT
Power (Engine power range)
390 - 460Hp
Torque Nm (Engine torque range)
1750; 1900; 2200
Brake System
Air Type disk brake of front and rear; Auxiliary brake; UD Extra Engine Brake (EEB); Variable geometry turbo brake
ECS (Emission control system)
Post New Long Term emission regulation
Usage
Semi Trailer; Car Carrier; Lorry; Marine Container; Tractor
With innovation that puts people first, our next-generation of trucks feature design enhancements in five major areas.
Drivability
Comfortable and efficient driving performance
“UD Active Steering”, a revolutionary technology that vastly improves steering precision and driver comfort, and “ESCOT-Ⅵ” – the latest evolution in 12-speed automated manual transmissions, plus disc brakes and an interior designed for driver comfort, deliver a sophisticated driving experience that reduces driver stress and fatigue.
Fuel Efficiency
The improved driveline achieves high level of fuel efficiency that enhances transport efficiency.
Both fuel-efficient, powerful and clean ”GH11 engine” and ”GH8 engine” with light-weight and compact while powerful torque comply with Japanese 2016 exhaust gas regulations.
ESCOT-VI’s road predictive function ”Foretrack”* and “Nenpi coach” advice support fuel-efficient driving.
* Standard for GH11 engine and ESCOT-Ⅵ mounted truck
Safety
Truly safe driving on a daily basis requires the vehicle to predict potential dangers and immediately notify the driver. Quon features safety systems based on advanced technology including Traffic Eye braking and Driver Alert.The goal of “safety that puts people first” mandates safe conditions for drivers as well as those in the surrounding environment. Safety is built into all basic features, with heat-dissipating, fade-resistant disc brakes available on all models.
Productivity
Chassis designed with cargo hauling in mind
The key to transport efficiency is superior loading performance. To improve loading performance, Quon uses high-tensile-steel plates for the main frame to reduce vehicle weight. Our chassis designs also emphasizes body-mounting efficiency to achieve the “Perfect Quon”.
Uptime
Complex, multi-layered interfaces and login procedures can make it difficult to access the detailed information when you need to make quick, positive decisions to choose the most efficient routes and maximize truck uptime. UD Telematics services will help you improve your profitability by maximizing vehicle uptime and fuel efficiency, while reducing unplanned stops and operational costs.
Uptime
Reliability and durability you can count on
Highly reliable and durable trucks are essential for ensuring the high levels of uptime and distribution that shippers demand. Quon achieves its unrivaled quality throughout the entire vehicle, easily passing tests in even the strictest environments. We support our customers’ businesses with reliability and durability that they can count on.
